Full Automatic Breadcrumb Making Machine Twin Screw Extruder High Efficiency

Automatic Breadcrumb Making Machine With Twin Screw Extruder ​

 Bread crumb Machine Introduction

Bread crumb is mainly used for fried beefsteak and drumstick as frying dressing. The long and sliver-shaped breadcrumbs are of porous structure inside. After frying, the crumbs become straight up bit by bit. They are not only puffed and nice in appearance but also crisp and delicate in taste. Breadcrumbs processing line is specially designed and developed according to market demand. It has changed the traditional technic.The whole line can be finished from the raw materials, extrusion, drying to finished products automatically.

The performance and quality have reached the highest domestic level of the line. From mixing materials, extruding, cutting, drying to finished products are done in one automatic line. The bread crumb is widely used as food coating additives on the surface of frying food like: frying chicken, fish, sea foods (shrimp), onion ring etc. The taste is fragrant, crispy, delicious and with rich nutrition.

Raw Materials: adopts corn flour, rice powder as raw materials

Capacity: 150kg/h, 240kg/h, 500kg/h

Flow chart:

Flour Mixing - Extruding and inflating –Flaking -- Cutting – Milling -- Conveying- Drying - -Cooling

Equipment list:

Mixer—— Screw conveyor—— Extruder——Flaking and Cutting machine -- Hoister——Dryer ——Sifter – Air Conveyor – Dryer --- Cooling Conveyor

Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers’ Local voltage according to different countries

Machines Materials: All the Bread crumb extruder machine are made by stainless steel, this line is with reasonable design and with high automation; the screws are made by alloy steel, with building block system structure and self-cleaning function

Technical Parameters:

Features of Our Bread crumb extruder machine :

A. Twin screw extruder with electricity heating system

a. The screws are made by alloy steel (38CrMoAL) and special craft by nitriding process, The HRC hardness is around 60---62, it has good self-cleaning ability and does not need to discharge or clean the barrel and screw, when roasting or replacing of materials.

b. The extrusion barrel is constructed of carbon steel, is made by #45 steel, stainless steel coating.

c. The gearbox has automatic lubrication function, with extends gear life.

d. Cutting knife fixed in the die head seat, rotary cutting by V-belt drive

B. Twin screw extruder with steam heating system ensure the most efficient, continuous and stable heating effects.

a. Big capacity feeding hopper, variable frequency speed, two stages mixing wings, fast and efficient mixing and feeding.

b. DDC Double axis differential conditioner, available for steam, Pre-cooking and high efficient.

c. Linear slide face cutting system, strong power, variable frequency speed and large output,

 Our Service

The service of the Bread crumb extruder machine

1.) Consultation service before, during, and after sales;

2.) Project planning and design service;

3.) Debugging of equipment until everything is functional;

4.) Management of equipments' long distance shipping from seller's factory to the named place by buyer;

5.) Training of equipment maintenance and operating personally;

6.) New production techniques and formulas;

7.) Provide 1 year complete warranty and life-time maintenance service.
